VIEW Wireless 220-240V IoT Connected Dimmer Mechanism – Bluetooth and Zigbee Dual Technology
Vimar VIEW Wireless connected electronic dimmer , compatible with smart home systems. Designed for regulating the light intensity of different types of loads, it supports:
Incandescent lamps: 20–200 W
LED lamps: 2–200 W
Electronic transformers: 20–200 W
Equipped with dual IoT technology, it works on both Bluetooth 5.0 (VIEW Wireless mesh) and Zigbee 3.0 networks, offering maximum integration flexibility.
Advanced features connected dimmer mechanism
Input for external button, which can be used to adjust the dimmer or recall a scenario.
RGB LED for location in the dark, with adjustable intensity.
Can also be configured as a switch, pending the installation of a dimmable lamp.
Compatible with dimmable LE and TE phase-cut lamps.
Multiple dimming possible with lamps of the same type.
Smart Home Compatibility
In Bluetooth mode, integrable with:
Amazon Alexa
Google Assistant
Apple HomeKit
IFTTT (via Vimar VIEW Wireless gateway)
In Zigbee mode, compatible with:
Amazon Alexa (via Zigbee hub)
Main technical data VIMAR LINEA 30805
Power supply: 220–240 V~ | 50/60 Hz
Mounting: built-in
Module: 1 (to be completed with interchangeable Linea Series key)
Technologies: Bluetooth 5.0 Mesh / Zigbee 3.0
Light signal: RGB LED
Setup and management: via VIEW Wireless app
What is a Vimar Linea electronic connected dimmer mechanism?
A connected electronic dimmer mechanism from the Vimar Linea Series is an advanced device that allows you to adjust the light intensity of compatible lamps in a precise and personalized way. Unlike traditional switches, the dimmer allows you to increase or decrease the light according to your needs, creating different atmospheres in each room.
The “connected” version integrates technologies such as Bluetooth and Zigbee , making the dimmer an active part of a smart home system. This means that, once connected via the VIEW Wireless app or voice assistants such as Alexa, Google Assistant or Apple HomeKit, it can be controlled remotely, automated and integrated into customized scenarios.
Aesthetically it matches perfectly with the Linea Series , known for its slim and modern design, and is designed for installation in flush-mounted boxes with interchangeable 1-module buttons.
