Chain Actuator WAY Mingardi Micro L 230V Stroke 280-380mm 350N
Chain actuator for: top hinged windows, bottom hinged windows.
MINGARDI linear electric actuator with reinforced double-sprocket chain inside the actuator body.
Operating voltage: 230V~ 50 Hz in conformity with Directives 2006/95 LVD - 2004/108 EMC.
Tested in accordance with the requirements of the European Standard EN 12101 - 2.
Outfitted with electronic limit switch system for opening and closing, which can be connected in parallel.
Colours available: anodised silver (A) - anodised black (N) - RAL 9016 (B).
Characteristics:
- High power;
- Double-link chain;
- Tested in accordance with the requirements of the European Standard EN 12101 - 2;
- Silicon cable;
- Protection degree IP 22;
- Limit switch closing-opening: Electronic.
Colour: Anodised silver (A) - Anodised black (N) - RAL 9016 (B).
Universal kit for fitting top-hinged windows (code: 2700090) sold separately.
Universal kit for fitting bottom-hinged windows (code: 2700092) sold separately.
Technical Features:
| DESCRIPTION |
VOLTAGE |
THRUST TENSILE |
STROKE |
CONSUMPTION MAX |
SPEED MIN. |
| Micro L |
230 V~ / 50 Hz |
350 N |
280mm 380mm |
110 W |
ca. 15 mm/s |
THE VALUES INDICATED ON THE TABLE ARE AVERAGE VALUES WERE RECORDED IN CONDITION OF NORMAL USE.
