IoT Connected Roller Shutter Mechanism VIMAR LINEA 30804

  • Brands: Vimar
  • Code: 30804
-38%
€ 49,41 € 79,70
Prices excluding VAT
IoT Connected Roller Shutter Mechanism VIMAR LINEA 30804 - Electronic Control
Are you looking for a product from the Vimar catalog that is not on our site? Contact us and ask for a quote.

- +

IoT Connected Roller Shutter Mechanism - VIMAR LINEA 30804 - Bluetooth and Zigbee Electronic Control

Vimar VIEW Wireless electronic device for controlling a motorized roller shutter with slat orientation function.

Equipped with a changeover relay output , it is compatible with cosφ 0.6 motors up to 2 A – 100-240 V~, and can be managed both locally and remotely.

It supports dual IoT technology, thanks to the standards:



  • Bluetooth 5.0 for VIEW Wireless mesh network

  • Zigbee 3.0 for integration with external home automation ecosystems



It includes an external button input , useful for recalling a custom scenario, and a function for recalling the preferred position of the roller shutter. An adjustable RGB LED allows the device to be located even in the dark.

Standard power supply 100–240 V / 50–60 Hz. To be completed with 1-module button from the Linea Series (not included).



Meccanismo Tapparelle Connesso IoT - VIMAR LINEA 30804



What is an IoT connected roller shutter mechanism?

An IoT connected roller shutter mechanism is an electronic device that allows you to control the opening, closing and orientation of a motorized roller shutter in an intelligent and automated way. Compared to traditional controls, this type of mechanism connects to the home network thanks to wireless technologies such as Bluetooth or Zigbee, allowing management both locally (via button) and remotely, via apps or voice commands.

In the case of the Vimar Linea Series, the mechanism integrates perfectly with the aesthetics of the other devices and can be customized with interchangeable 1-module buttons. It can also be inserted into smart scenarios (e.g. “Good morning”, “I’m leaving the house”) and configured to automatically reach a preferred position of the roller shutter.

It is the ideal choice for those who want to automate their roller shutters and integrate them into a smart home system without masonry work, taking advantage of the simplicity of the Vimar VIEW Wireless system.
