Bettio mosquito net Mini 31 with windproof Vertical Guide to Spring

Bettio mosquito net Mini 31 with windproof Guide - Vertical Spring

Mini is a mosquito net made of fiber-glass and represents the response BETTIO to the problems of space.
At the minimum overall dimensions, must be added the ease of assembly: in fact its heads are equipped with springs which support the box when it is placed in the upper part of the hole in filarci under the guides, without the need to secure it.
Then without neglecting the importance of the guides windproof, which hold perfectly the network within them even with strong drafts.

Safety clutch
The safety clutch allows the mosquito to rewind gradually avoiding dangerous impacts of the loss of control of the mesh bar.
The clutch is an option but is mandatory on mosquito nets vertical height greater than 2 meters.

For basic measures less than 625 mm and a height greater than 1500 mm, the manufacturer of mosquito nets Bettio does not ensure the possibility of inserting the clutch (to occur a case by case). If for technical reasons it was not possible to engage the clutch, the mosquito net will still be produced within specified time points and the additional cost of the clutch will be returned to the customer.

Adjustable carrying handle
The carrying handle slides along the bar handle and you decide the point at which attach using the special dowel, with reference to any impediments present in the installation hole.

Tested with support spring
The heads and controtestate side are spaced apart by an internal spring which, thanks to its thrust, keeps the dumpster stationary, facilitating the installation operations.

Guiding and windproof (international patent Bettio)
It is a special profile, equipped with a brush longer and more rigid than normal.
In strong winds, the brush rotates in the special slot, pulling the mesh, preventing the escape from the guide.



Technical features:

• Model: Mini;
• Overall dimensions: 31mm;
• Settings: using tested up to +4 mm per side;
• Recommended application: window;
• Finish network: no ribbon and buttons;
• Aluminum color: choose between silver (painted silver), Bronze (bronze painted), Black (opaque electro ELOX 2000), White (glossy white RAL 9010), Ivory (ivory polished Ral 1013), Green (green matt Ral 6005), brown (brown matt Ral 8017), Cherry Wood, Walnut, Douglas, Pine and White Cream (Ral 9001). Estimates are made on request for other colors.

The importance of the mosquito net
Why install mosquito nets in the environments in which we live? To protect yourself from mosquitoes, what else? In fact, the response seems very low cost. But to linger a bit 'on the application you can also find plenty of other good reasons as to why protect the environments in which we live with mosquito nets.
For example, thanks to mosquito nets, while pesky mosquitoes if they are left out, we can keep the windows wide open to regenerate the air inside our house: a good air circulation ensures well-being, a good sleep, a high degree of concentration and yield. Do you think that the air inside your home or office can be up to 5 times more polluted than the air outdoors.
We spend 90% of our time indoors, at home, at school or at work, breathe about 22,000 times every 24 hours.
Let's not forget the importance of light: the sun is light and light is a "super nutrient." The sun acts as a natural antidepressant: what could be better for our mood that open the windows and let the light (and only you) enter into our homes?
Moreover, thanks to mosquito nets remain outside our house also flies, bugs, spiders, and certainly many other insects that, without sting, there surely rejoice.
And yet: the mosquito net can save power by limiting the use of facilities for the treatment of air, such as air conditioners.
An advantage for the environment and for human health, but consequently also an economic advantage.

Sustainability: the mosquito nets Bettio are 90% recyclable
At a time when talk of "green economy" seems to have become almost a fad, Bettio carefully evaluates the environmental impact of its products.
This vision drives the company to design, produce and offer products created with high quality materials, durable and which, for their end use, require very minimal maintenance.
Corporate ethics fall also the continuing effort to create a safe working environment and a willingness to comply with the standards. In this sense, then a material such as aluminum, 100% recyclable, fits perfectly with the philosophy of "green" of the company, as well as the recycling of the almost totality of production waste.
Finally, the entire production process is highly automated and takes place aiming to energy saving.
